  • 32inch PCAP Touch Monitor
  • 32inch PCAP Touch Monitor
  • 32inch PCAP Touch Monitor
  • 32inch PCAP Touch Monitor
32inch PCAP Touch Monitor 32inch PCAP Touch Monitor 32inch PCAP Touch Monitor 32inch PCAP Touch Monitor

32inch PCAP Touch Monitor

touch monitor  , 32inch monitor  , 3M touch monitor  , kortek 32inch  , bestech 32inch  , touch screen
Inquiry Send Email

Description


Specification

Case/ frame color

Black color

Display type

Active matrix TFT LCD, LED backlight

Screen Diagonal

32"diagonal

Aspect ratio

16:9

Resolution(pixel)

1920*1080

Display Colors

16.7M

Brightness (Standard)(cd/m2)


LCD panel: 300 nits(Typ.)

Response time (standard)

5 ms

View Angle(from center)

Horizontal (left / right): ±89°
Vertical (up / down): ±89°

Contrast (standard)

1000: 1(Typ.)

Input video format

VGA and HDMI

Power consumption

Display only: 13.5W(Typ.)

Temperature

Operating: 0°C to 40°C; Storage: -20°C to 60°C

Humidity

Operating: 20% to 80% (no condensation); Storage: 10% to 90% (non-condensing)

MTBF

50,000 hours

Warranty

1 year

Screen Display (OSD)

Digital OSD

Mounting options

75mm VESA mounting


32inch , the size most used in  Jackpot , Slot machine , Lottery Terminal ,
Lottery Vending , Bingo , Sports Betting , Slot machine , also in Redemption Kiosk ,

Cash Kiosk , Vending Terminal machine , Amusement machine ,Wayfinding ,
Information Inquiry machine , Roulette etc.
